High vacuum electromagnetic differential pressure inflation valve

GYC-JQ series high vacuum electromagnetic differential pressure charging valve is a special valve installed on the mechanical vacuum pump. It is installed at the air inlet of the mechanical vacuum pump and is turned on and off synchronously with the pump. When the pump stops working or the power supply is suddenly interrupted, the valve can rely on the pressure difference between the atmosphere and the vacuum to automatically close the valve plate, close the vacuum system, maintain its vacuum degree, and fill the air into the pump chamber through the orifice of the valve. , to avoid the backflow of pump oil from contaminating the vacuum system. The applicable working medium is air and non-corrosive gas.

• Applicable range (Pa) 10⁵~10^-3
• Valve leakage rate (Pa.L/S) <1.0×10^-4
• Power supply voltage (V/Hz) 220/50
• Medium temperature (℃) -25~+50
• Switching time ≤3
• Installation method vertical or horizontal
• Flange standard GB4982
